New Icon
Truth Logo

$3,400.00$7,499.00

Our lightest, lowest and most efficient xc bike ever. The truth is built to make your best better and devour xc stages with ease and power. An all out race machine with 100mm option for ultimate attack mode.
TRAVEL:100/120mm
WHEEL SIZE: 29
USAGE: XC / Trail

20% restocking fee if the bike is ready for shipment and not taken by the client.

FEATURES

Bottom-Bracket

Lowest center of gravity
in Ellsworth history

The goal was to capture the legendary instant center tracking suspension in the most compact and integrated package possible. This creates a precise handling, flawless suspension function and amazing acceleration.

ShocK

Custom Fox Float with
Titanium hardware

Easy to reach shock adjustment negates the need for a complicated cockpit. Titanium bolts provide the best quality hardware possible.

SHOCK-CRUD-GUARD-

Shock
"crud-guard"

The specially designed crud-guard protects the shock from crud, and the accumulation of crud on the inside of the stay and downtube area.

HEX-TAPER-AXLE-2

Hex taper
axle

Our proprietary hex taper axle prevents the two dropouts from torsional independence. This locks the lateral movement of the left and right stays of the bike.

Overview

The Truth upsets what people currently accept as functional suspension. It’s a product of the culmination of 25 years of design and technology integration that hinges on the same three imperatives that have always driven Ellsworth bike design - Improved Traction and Control, Always Active Suspension, and Energy Efficiency. The simple result is this; those who ride the Truth will be able to go farther and faster with less fatigue.

Truth-Action-Shot-1
Truth-Geo.svg
S
M
L
1. Head Angle (deg)
69
69
69
2. Seat Angle (deg)
75.5
75.5
75.5
3. Stack (mm)
585
594
604
4. Reach (mm)
420
445
469
5. Head Tube (mm)
98
109
120
6. Top Tube (mm)
572
600
627
7. Seat Tube (mm)
381
432
483
8. Standover (mm)
629
629
629
9. Front Center (mm)
683
712
741
10. Chainstay (mm)
435
435
435
11. BB Height (mm)
327
327
327
12. Wheelbase(mm)
1118
1147
1176
Active-Logo.svg

The Active Suspension on the Truth is designed so that it is always active. It’s always reacting and responding (compressing and rebounding) to bump input from the trail. It’s always working to maintain better contact with the trail for increased traction and control. It’s always working to help you go farther and faster with less fatigue. Suspension must be fully active. In other words, it must work all of the time if it is to be of positive effect on the rider experience.

Zero Chain Growth

The Truth exhibits zero chainstay growth throughout the suspension travel range. This means that there is zero feedback through the pedals as the rear suspension cycles through its travel range. It’s another reason that you can pedal forcefully through rough sections of trail without constraining the rear suspension via drivetrain forces, leaving the bike able to constantly and actively manage bump response and maintain traction and control.

Zero-Chane-Growth.svg

Vertical Axle Path

The vertical axle path on the new Truth is a result of the far-forward instant center placement, and it ensures that bump response is managed in a neutral fashion. Since mountain biking takes place on truly dynamic terrain, from square-edged bumps producing high speed compression events or rolling, low frequency bumps producing low-speed compression events, this neutral, active demeanor is important. It means that the rider on the Truth feels less bump impact through the bike, and that the suspension can better maintain contact with the trail surface for increased traction and control.

Verticel-Axle-Path.svg

Boost Spacing As Per Industry Standards

Like the rest of the Ellsworth lineup, the Truth utilizes boost hub spacing. Incorporating an extra 6mm in the rear and 10mm in the front hubs yields great rewards with increased bracing angles for the spokes. This adds significant lateral stiffness to the wheels increasing performance and durability as well. Boost hub spacing also allows clearance for bigger tires as the chainline moves outboard to 52mm, freeing up that crucial space for the driveside chainstay between the tire and chainring.

Boost-Spacing.svg

Integrated Front Headset

The Truth now utilizes a fully integrated headset. It’s a more intricate manufacturing process, but it introduces simplicity, style and performance to the Truth. By doing so, we’ve also reduced maintenance and eliminated possible creaking.

Integrated-Front-Headset.svg

SHOCK

Foxx-Float-Shock

FOX FLOAT FACTORY

Specs

Large diameter main piston, valving, and IFP for increased performance, consistency, and tuneability
Lightweight, one-piece EVOL air sleeve improves responsiveness and sensitivity
MCU bottom-out bumper for end-stroke progressivity
Factory Series models feature Genuine Kashima Coat
Weight: 310 g
Size: 185 x 52.5mm
Adjustment: 2pos-Adj

Fork

Fox-Fork

FOX 34 FACTORY SC

Specs

The lightest 34 ever, the all-new 34 Step-Cast is designed from the ground up to deliver uncompromising XC race performance with class leading tunability, chassis stiffness and strength.

Upper Tube Finish: Kashima Coat
Rotor Size: 160 direct Post Mount, Up to 180 compatible
Air Spring: FLOAT EVOL
Steerer: 1.5 Taper
Weight: 3.30 lb / 1496 g

SEATPOST

Dropper-Post

FOX Factory Transfer

Specs

The Transfer seatpost is lighter and tighter than ever before. Less weight, reduced length and decreased insertion depth means a better fit on more frames. Improved durability and easier serviceability means more riding and less downtime.

  • Patent-pending clamp design dramatically reduces stack height
  • Proven Transfer internals with even easier serviceability
  • Reduced overall length and insertion depth
  • Low lever force provides consistent actuation pressure even with saddle weighted or unweighted
  • Internal Cable routing
  • 125mm Drop: 363.5mm total length; 100mm min. insertion; 200.2 max insertion

WHEELSET

Rim

Industry 9 UL300 CARBON

Specs

Effortless speed meets agile handling, executed with the best materials available. When the objective is getting from Point A to Point B in the fastest time, the Ultralite 300 is the ideal companion. The highest-performing XC wheelset in our line-up, make no mistake this is the choice for when every second counts and every gram is considered. We’ve refined the rim shaping for better tire retention and strength to width over our previous generation Premium Carbon UL rim, so you can be sure that we obsess over the details as much as you do.

Size: 29”
Hole Count:24
Rim Inner Width: 30.0mm
Set Weight: 1470g
